Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
1-4W power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous flux（LM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3535 | MH-3535QAQWC | Amber | 3.0 | 3.4 | 260 | 320 | 1800 | 200 | 700 | 120 |
| White | 3.0 | 3.4 | 260 | 320 | 5000 | 6000 | 700 | 120 | ||
