Customized service:we can produce the smd led according to the parameters and package size
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity（LM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Max | Min | Max | Min | Max | ||||||
| 5054 | MH-5054RGBW | Red | 1.8 | 2.4 | 15 | 20 | 620 | 630 | 180 | 120 |
| Green | 2.8 | 3.4 | 35 | 45 | 515 | 525 | ||||
| Blue | 2.8 | 3.4 | 10 | 20 | 450 | 465 | ||||
| White | 3.0 | 3.4 | 60 | 70 | 1500 | 10000 | ||||
